Ubiquiti Switch-FlexXG Network Switch Jeddah
Ubiquiti Switch-FlexXG Jeddah comes with a slim, compact housing that can easily be mounted on a desktop. It is a fully managed, multi-gigabit, Layer 2 switch with (4) 10GbE RJ45 ports and (1) GbE PoE input. This switch can also be monitored or configured from anywhere with the powerful, intuitive UniFi Network web application and mobile app.
Easily expand your network with the UniFi Switch Flex XG (USW-Flex-XG), a highly configurable, managed, 10GbE Layer 2 switch with five RJ45 Gigabit Ethernet ports, including one PoE Gigabit input and four 10GbE RJ45 Ethernet ports. Sporting a compact, slim design, the USW Flex XG delivers high-performance switching in any environment and is centrally managed in the UniFi Network application.
Features:
- (1) GbE, 802.3at PoE+ RJ45 input
- (4) 10GbE RJ45 ports
- Compact, slim housing
- Can be powered with a 5V, 5A USB-C adapter
Technical Specs
| Mechanical | |
|---|---|
| Dimensions | 135 x 185 x 32 mm (5.31 x 7.28 x 1.27″) |
| Weight | 1.2 kg (2.65 lb) |
| Enclosure Material | Polycarbonate |
| Hardware | |
| Total Non-Blocking Throughput | 41 Gbps |
| Switching Capacity | 82 Gbps |
| Forwarding Rate | 61.012 Mpps |
| Max Power Consumption | 25W |
| Power Method | (1) 802.3at PoE, 50-57VDC, 25W (1) USB Type-C, 5VDC, 5A |
| Power Supply | 802.3at PoE (Pins 1, 2+/3, 6- or 4, 5+/7, 8) AC/DC Power Adapter, 5VDC, 5A, 1.5 m Cord (Included) |
| Supported Voltage Range | 90 to 264VAC (Adapter) |
| Management Interface | Ethernet In-Band |
| Networking Interfaces | (1) 10/100/1000 Mbps RJ45 Ethernet (4) 100/1,000/2,500/5,000/10,000 Mbps RJ45 Ethernet |
| Services | SMB Layer 2 Gigabit Ethernet Switch |
| ESD/EMP Protection | Air: ± 16 kV, Contact: ± 12 kV |
| Button | Factory Reset |
| Operating Temperature | -5 to 45° C (23 to 113° F) |
| Operating Humidity | 10 – 90% Noncondensing |
| Certifications | CE, FCC, IC |
| LEDs | |
| System | (1) Power, Blue/White Flashing White : Bootup in Progress Flashing Blue : Firmware Upgrading Steady White : Factory Defaults, Awaiting Adoption Steady Blue : Device is Adopted |
| Ethernet | White : Link or Activity |
